Fardriver ND72300b Encoder
Encoder-compatible FOC sine wave controller for 48-72V encoder motors. 300A phase current, 100A DC rated. Same F1/S12 housing as the standard ND72300 but supports encoder motor feedback instead of hall sensors — uses 8-pin motor connector. Compatible with Tuttio Soleil 01 and similar encoder-equipped e-motos. Built-in Bluetooth for wireless programming via Andro4A app. Not plug-and-play for stock Tuttio — requires replacing stock display/throttle assembly.
In brief: 48–72V controller. 100A continuous. FOC, dual mode, regen, field weakening, self-learning support. From $175.
Type
- VESC Based
- No
Electrical
- Voltage Range
- 48–72V
- Continuous Amps
- 100A
- Max Phase Amps
- 300A
Motor Features
- Regen Support
- Yes
- Drive Mode
- FOC
- Sensor Mode
- Dual Mode
- Field Weakening
- Yes
- Self-Learning
- Yes
- Dual Motor Support
- No
- Controller Pairing
- No
Inputs
- Throttle Support
- Yes
- PAS Support
- No
Display
- Supports Display
- Yes
- Requires Display
- No
- Protocols
- SiAECOSYS CAN BUS
Power Switch
- Supports Power Switch
- Yes
- Requires Power Switch
- No
- Requires Pre-charge
- No
Programming
- Via Display
- No
- Via Phone
- Yes
- Via PC
- Yes
Physical
- Weight
- 1 kg
- Dimensions (L×W×H)
- 102.0mm × 174.0mm × 52.0mm
- IP Rating
- IP67
Ports & Connectors
Power Input2-position Screw Terminal Block
Power
1Battery +
2Battery -
Phase Wires3-position Screw Terminal Block
Motor Phase
1Phase A
2Phase B
3Phase C
30-Pin Function Connector
Hall Sensor
TemperatureHall Sensor
15V Power
2Motor Temp
3Ground
4Hall C
5Hall B
6Hall A
Door Lock1 wire
Display
1Door Lock
Display (ONE-LIN)
Display
1One-Wire Comm
High/Low Speed
Display
1Gear High
2Ground
3Gear Low
Backward Gear
Display
1Reverse Signal
2Ground
Cruise/BOOST
BrakeDisplay
1Parking / E-Brake
2Gear Sport
Throttle
Throttle
1Ground
2Throttle Signal
35V Power
Brake (High 12V)
Brake
1Brake Signal (High)
Brake (Low 0V)
Brake
1Ground
2Brake Signal (Low)
Speed Pulse
Speed Sensor
1Speed Signal
Programming Port
UART
15V Power
2UART RX
3UART TX
4Ground
CAN High1 wire
CAN Bus
1CAN High
CAN Low1 wire
CAN Bus
1CAN Low
Alarm Power
security
1Ground
2Alarm Power
Anti-theft
security
1Anti-Theft Key
2Anti-Theft Signal
3Wheel Signal
