VOTOL EM100 GTR
VOTOL EM100 GTR is a higher-boost variant of the EM100 family — 48-72V sinewave controller with 80A rated DC / 150A boost / 450A peak phase (~3kW). 2025 revision with increased peak phase current vs the base EM100. Suited for 3kW PMSM/BLDC motors — commonly paired with QS120 mid-drive motors in e-moto builds. Features flux weakening, IP67 waterproofing, LIN/CAN communication. Uses VOTOL's standard EM/SV-series Wiring A architecture: 3 flush Mini-Fit Jr headers + screw terminals for power/phase. Programmable via PC.</description> <parameter name="adminNotes">Source: AliExpress (Dun / SIAECOSYS / LANDE family listings). Specs: 80A rated DC / 150A boost / 450A peak phase / 48-72V / 3kW. Higher-boost variant of EM100 (base EM100 has 100A/120A/300A). **Wiring (admin-verified 2026-04-18):** Standard Wiring A (flush Mini-Fit Jr 3-Molex + screw terminals). Per admin, EM100 GTR/GTS and EM180 GTS all use the standard flush Molex architecture despite their 'EM100/2' marketing naming. VOTOL naming note: listings call this 'EM100/2 GTR' with the '/2' possibly implying 'Gen 2' (higher-boost rev of the base EM100), but the connectors are NOT the shrouded EM100-4P style — they're standard flush like the base EM100.
In brief: 48–72V controller. 80A continuous. 150A peak. Sinewave, sensored, regen, field weakening support. From $139 across 2 sellers.
Type
- VESC Based
- No
Electrical
- Voltage Range
- 48–72V
- Continuous Amps
- 80A
- Peak Amps
- 150A
- Max Phase Amps
- 450A
Motor Features
- Regen Support
- Yes
- Drive Mode
- Sinewave
- Sensor Mode
- Sensored
- Field Weakening
- Yes
- Self-Learning
- No
- Dual Motor Support
- No
- Controller Pairing
- No
Inputs
- Throttle Support
- Yes
- PAS Support
- No
Display
- Supports Display
- Yes
- Requires Display
- No
- Protocols
- SiAECOSYS ONE-LIN, SiAECOSYS CAN BUS
Power Switch
- Supports Power Switch
- Yes
- Requires Power Switch
- No
- Requires Pre-charge
- No
Programming
- Via Display
- No
- Via Phone
- No
- Via PC
- Yes
Physical
- Weight
- 1.65kg
