VOTOL EM30SP (LIN)
VOTOL EM30SP is an entry-level 48-72V sinewave controller with 32A rated DC / 37A boost current, suited for 500-1000W PMSM/BLDC motors in small e-scooter / e-bike builds. Tier above EM25P — adds the full alarm/anti-theft system with the 3 Molex connector layout. Features flux weakening, IP67 waterproofing, LIN communication, and programmable via PC. Uses the standard VOTOL 'Old Version' EM/SV-series connector architecture: 3 flush Mini-Fit Jr headers (function 2×8, alarm 2×4, hall 2×3) + screw terminals for power/phase. Programmable via the Old Version USB cable.
In brief: 48–72V controller. 32A continuous. 37A peak. Sinewave, dual mode, regen, field weakening support. From $48 across 6 sellers.
Specs verified Jul 20, 2026
